| Brand Name: | XIANZI |
| Model Number: | pof low |
| MOQ: | 500kg |
| Price: | 3 usd/kg to 6 usd/kg |
| Payment Terms: | T/T |
POF Low-Temp Shrink Film for 3C Electronics 10-18μm
Outer box packaging for 3C electronic products must protect sensitive components from moisture and dust while keeping contents visible. This POF low-temperature shrink film uses a multi-layer co-extruded polyolefin formula that starts shrinking at a low temperature, completing the process within 55–85°C. This avoids heat damage to the housing or internal parts of earphones, chargers, and data cables. The film offers good clarity and shrinks tightly around boxes to show product outlines. The center-fold format suits automatic packaging machines, with reliable sealing and low cracking. It is suitable for outer packaging or bundle wrapping of mobile phone boxes, earphone boxes, charger boxes, data cable boxes, smartwatch boxes, tablet boxes, and other 3C products. Folded width, thickness, and roll length can be customized.
| Parameter | Specification | Test Method | Standard Reference |
|---|---|---|---|
| Thickness | 10 – 18 μm (standard 12 / 15 μm) | ISO 4593 (unembossed film) | ISO 4593:1993 |
| Folded Width | 180 – 700 mm (customizable) | Standard Gauge | Standard Gauge |
| Density | 0.90 – 0.92 g/cm³ | ISO 1183 | ISO 1183 |
| Tensile Strength (MD/TD) | ≥ 80 / 90 MPa | ISO 527-3:2018 | ISO 527-3:2018 |
| Elongation at Break (MD/TD) | ≥ 350% / ≥ 400% | ISO 527-3:2018 | ISO 527-3:2018 |
| Heat Seal Strength | ≥ 3.5 N/15mm | ASTM F88 | ASTM F88 |
| Light Transmittance | ≥ 87% | ASTM D1003 | ASTM D1003 |
| Haze | ≤ 4.5% | ASTM D1003 | ASTM D1003 |
| Gloss (45°) | ≥ 70 GU | ASTM D2457 | ASTM D2457 |
| Shrinkage (MD/TD) | ≥ 40% / ≥ 45% (70°C, 30s) | ASTM D2732 | ASTM D2732 |
| Shrinkage Temperature Range | 55 – 85°C | In-house method | In-house method |
| Surface Tension | ≥ 34 mN/m | ISO 8296 | ISO 8296 |
| Roll Length | 800 – 3,000 m per roll | Counter system | Counter system |
| Core Diameter | 76 mm / 152 mm | Standard Gauge | Standard Gauge |
This product is tested according to the following international standards: ISO 4593 for thickness, ISO 527-3 for tensile properties, ASTM F88 for heat seal strength, ASTM D1003 for light transmittance and haze, ASTM D2457 for gloss, ASTM D2732 for heat shrinkage, ISO 8296 for surface tension, and ISO 1183 for density. Low-temperature shrinkage performance is evaluated under in-house method at 55–85°C.
Mobile phone box packaging
Earphone box packaging
Charger box packaging
Data cable box packaging
Smartwatch box packaging
Tablet box packaging
Other 3C electronic product outer packaging
